Description
Description
Suitable for use with clean water that does not contain abrasive particles and with liquids that are not chemically aggressive towards the materials from which the pump is made.
The hydraulic characteristics of these pumps, coupled with their compactness, makes them suitable for use in industrial applications.
Installation needs to be undertaken in well ventilated closed areas or anyway protected from bad weather.
Features
Liquid type:Clean Water
Uses:industrial
Applications:cooling systems, air conditioning systems, ironing system
typology:surface
Family:peripheral
Performance Range:
- Head up to80 m
Application Limit:
- Temperature of the liquid from -10 C to +90 C
- Ambient Temperature da -10 C to +40 C
(+50 C for PQ 60-Bs)
- Manometric suction lift up to 8 m
- Max. working pressure 10 bar
- Continuous service S1
