Description
Built for high flow and long service life, the Pearl 4PWS70G100 is a 4″ stainless steel submersible pump end (motor not included) rated 10 HP / 7.5 kW with a 2″ NPT discharge. Its ideal for deep-well potable water, irrigation, municipal/industrial service, pressure boosting, and fountains. The 4PWS series uses corrosion-resistant 304 stainless steel hydraulics with a high-strength 431 stainless steel shaft and an integrated check valve for easy, reliable installation.
Key specs
-
Model: 4PWS70G100 (70 GPM series) pump end only; motor sold separately.
-
Power: 10 HP (7.5 kW) Stages: 16 Discharge: 2″ NPT Outside diameter: 3.86″ (98 mm) fits 4″ wells.
-
Materials: 304 SS impellers/diffusers, discharge head & strainer; 431 SS shaft; built-in check valve; NEMA mounting.
-
Recommended flow range: 2587.5 GPM Max liquid temp: 86 F (30 C) Warranty: 2 years.
Performance (Total Dynamic Head) 4PWS70G100
-
0 GPM: 515 ft
-
12.5 GPM: 514 ft
-
25 GPM: 500 ft
-
37.5 GPM: 475 ft
-
50 GPM: 450 ft
-
62.5 GPM: 415 ft
-
75 GPM: 368 ft
-
87.5 GPM: 300 ft.
Dimensions & weight
-
Length (A): 48.03 in (1220 mm) OD: 3.86 in (98 mm) 2″ NPT discharge Net weight: 26.74 lb (12.1 kg).
Applications
Potable water supply from deep wells, agricultural irrigation & livestock watering, municipal/industrial systems, pressure boosting, and fountains.
Compatibility
Pairs with standard NEMA 4″ submersible motors rated 10 HP (select voltage/phase as required for your installation; motor not included).
